Advantages
◎ Microfluidics-optimized discharge air gap design;
◎ Proprietary aluminum electrode micro-arc oxidation technology;
◎ High-efficiency air or water cooling technology;
◎ Integrated plug-and-play design;
◎ High-frequency, high-power factor digital power supply;
◎ Voltage and current dual closed-loop control algorithm;
◎ Dynamic frequency adaptive optimization control;
◎ Pre-set multi-operating mode optimization strategy;
◎ Alumina ceramic barrier discharge dielectric;
◎ User-friendly graphical human-computer interface design.
Parameter
Product Series | MOS |
Ozone production | 20-100g/h |
Ozone concentration | 150mg/L |
Ozone concentration adjustment range | 120-200mg/L |
Operating pressure | 1-3Bar |
Energy consumption(kwh/kg) | 7@10wt% |
Intake requirements | Oxygen-rich source, oxygen purity > 93% |
Cooling water inlet temperature | <28℃ |
Cooling water pressure | 1-3Bar |
Chiller configuration | Closed loop, water cooling, water temperature 28℃ |
Automatic program | Cold start (15 minutes), hot start (30 seconds), shutdown, standby |
Automatically adjust production | 10-100% adjustable |
Remote Control | RS485/Modbus |
Sealing level | IP52 |
Operation interface | HMI human-computer interaction |
Power | 220V/2Ph/50HZ |
